Ürün No: BE3004



Açık akış oranı: 189 Litre/dak

Akış oranı (1 metre): 170 Litre/dak

Maksimum atış mesafe: 4,6 metre

Voltaj: 24 Volt

Akım tüketimi: 15 amper

Kablo kesiti: 1.5mm²

Ağırlık: 2,64 kg

Hortum bağlantı çapı: 32mm

Yükseklik: 195mm

Genişlik: 166mm

Derinlik (çap):132mm



------------------------------------



Whale ORCA Series 3000 - 24V Electric Bilge Pump

Compact, Powerful and Automatic Electric submersible bilge pump with wide product range. A separate bilge floater is required.



Superior Advantages;

• Easy installation
• Longer life battery with low energy consumption
• Easy to maintain thanks to easy access to motor and filter area
• Smooth adaptation to compact bilge areas
• Five different capacity alternatives
• CE and NMEA approved



MODEL ORCA 3000-24

Product Number: BE3004



Open flow rate: 189 ltrs/min (3000 US GPH)
Flow rate at 1 meter: 170 ltrs/min (2700 US GPH)
Maximum discharge head: 4.6m (15ft)
Voltage: 24V d.c
Current consumption: 15 amps
Cable cross section:  1.5mm² (16AWG)
Weight: 2.64kg (5.8lbs)
Hose connection diameter: 32mm (1^1/4'')
Height: 195mm
Width: 166mm
Depth (diameter): 132mm
