Blue Sea 285 Series Panel-Mount Breaker 100A - 7087-BSS

Blue Sea 285 Series Panel-Mount Breaker 100A - 7087-BSS

Price : €53,50  + VAT
Incl. VAT : ₺3.438,68
Price in TL : ₺2.865,57(₺573,11 + VAT)
iskontoen
Blue Sea 285 Series Panel-Mount Breaker 100A - 7087-BSS
:

Blue Sea 285 Series Panel-Mount Breaker 100A - 7087-BSS

Blue Sea Systems Automatic Circuit Breaker 100 Ampere - BSS 7087. Features thermal bimetal circuit breaker technology. Combined switch and circuit breaker function. Safe operation with "Trip-Free" feature. Visual reset lever with open status indicator. Ignition protected construction (SAE J1171 standard). Waterproof design.



Key Features

  • Thermal bimetal circuit breaker technology
  • Combined switch and circuit breaker function
  • Safe operation with "Trip-Free" feature
  • Visual reset lever with open status indicator
  • Ignition protected construction (SAE J1171 standard)
  • Waterproof design


Technical Specifications

Parameter Value
Product Code 7087
Current Capacity 100A
Maximum Voltage 48V DC
Breaking Capacity 3000A @ 48V DC
Operating Temperature -40°C to 85°C
Mounting Type Panel mount
Terminal Type M6 screw connection (accepts 1/4" ring terminals)
Terminal Torque 6.78 Nm (60 in-lb)
